7.2 Part List Tables
Table 7.2.1- List Of Items Of Chapter 9
FIG./POS.
Description
Drawing
Specification
Number or Type
Required
Quantity
(N)
Figure 9.1.2 6' Antenna X-Band
304465G1
1
“ 9’ Antenna X-Band
304465G2
1
“ 12’ Antenna X-Band
304465G3
1
Figure 9.1.5 Motoreducer assy for 6/9’ antennas
304280A2
1
Figure 9.1.5 Motoreducer assy for 12 antenna
TBD
1
Figure 9.1.4, pos.5 Brushless motor driver
304427A1
1
Figure 9.1.27, pos.2 X Band Magnetron 12 KW
89A504P024
1
“ X Band Magnetron 25 KW
89A504P023
1
Figure 9.1.28 RF Amplifier assy
304214A1
1
Figure 9.1.6 Main electronics assy 12 KW
304212A2
1
“ Main electronics assy 25 KW
304212A3
1
Figure 9.1.2 Performance Monitor Arm
304316A1
1
