SRT X-BAND RADAR SYSTEMS
TROUBLESHOOTING
304202P003 5.1 Rev. C
Table 5.2.1 - List Of Main Possible Failures)
TXRX does not turn on
Transmitter can't be controlled
Antenna data can't be controlled
Transmitter performance is low
Sector Blanking is not working
Antenna does not rotate
There is no current to magnetron
Transmitter does not generate RF
Antenna rotates, but rotation speed cannot
be controlled
Potential Cause Check Remedy
x
Power supply is missing or polar-
ity is inverted
Check DL1 Led status and measure voltage on TB2 of PCB SRT_Power
Connect the 24VDC volt-
age to the transmitter
properly
x
Power_ON signal is missing
Close P1 link on PCB SRT_Power and make sure the Led DL2 lights on
properly
Replace SRT_Control
Board
x
Voltage supply is too low Check DL1 Led Status and measure voltage on TB2 of SRT_Power Board
Connect the 24VDC volt-
age to the transmitter
properly
x x x x
BNC video cable is interrupted Check electrical continuity and insulation from GND
x x
Video signal is low
Check video signal and data signal amplitude on TP1 (VD Out) of REI 2K
Board
Adjust amplitude properly
x x
Magnetron exhausted Check magnetron transmission hours and current Need check on console Replace magnetron
x x
The safety switch is open Check switch position and continuity
Close the safety switch or
replace it
x x
High voltage generator is dam-
aged
Disconnect 700V cable from TB3 of SRT_Power Board, disconnect mo-
tor cables, turn S1 of the SRT_Control Board on position 3 and make sure
DL3 is off.
Replace SRT_Power
Board
x x
Cable between Bearing Reader
and SRT_Control boards is
interrupted
Check electrical continuity of the cables Replace cable
