10.3 Check-List for Electrode Connection and ECG cable
Electrode Location
Electrode Code
Socket Number
Right Alarm
RA/R
9
Left Alarm
LA/L
l0
Left Leg
LL/F
11
Right Leg
RL/N
14
Chest 1
Vl/Cl
12
Chest 2
V2/C2
1
Chest 3
V3/C3
2
Chest 4
V4/C4
3
Chest 5
V5/C5
4
Chest 6
V6/C6
5
Note:
1. Please apply leads in the close state.
2. Please check the electrode contact the skin well or not, if the ECG didn't appeare for
a long time, then press the start key which will close in several milliseconds several
times.
3. please apply conductive jelly when place electrode.
