3. Each Component Function
20 IPC-PT/MV10 / IPC-PT/LS10 / HPC-HMV10 / HPC-HLS10 Hardware Manual
PCMCIA (PCMCIA)
PCMCIA compliant card slots are provided [TYPE II
×
2 (TYPE III
×
1) size].
Slot 1
Slot 2
Figure 3.8. Slot Numbers and Locations
CAUTION
A type III card should be inserted into slot 2.
Attaching the card removal prevention fitting
PCMCIA Card
Figure 3.9. Attaching the card removal prevention fitting
Power Supply to the Card
The voltage that can be used and the current capacity of each slot are as shown below:
Table 3.10. Power Supply to the Card
Voltage Current capacity (Max.)
+5V 250mA/Slot
+3.3V 250mA/Slot
+12V Not supplied.
