Contec IPC-PT/MV10 Series Hardware Manual

2. Overview
IPC-PT/MV10 / IPC-PT/LS10 / HPC-HMV10 / HPC-HLS10 Hardware Manual 7
2. Overview
Specifications
Functional Specifications
Table 2.1. Functional Specifications
Type IPC-PT/MV10 series, HPC-HMV10 series IPC-PT/LS10 series, HPC-HLS10 series
LCD type 10.4-inch TFT color LCD (640×480) 12.1-inch TFT color LCD (800×600) LCD type
Number of colors 65536
Resolution 4096×4096 (emulated in 640×480 mode) 4096×4096 (emulated in 800×600 mode) Touch panel
Detection method Analog resistive
Type SH4 HD6417751RBP 240MHz
Internal cache Data: 16KB, Instruction: 32KB
CPU
Clock frequency 240MHz
Flash memory
(NFDISK) *2
32MB
System memory 128MB SDRAM
Memory
OS loading
Flash memory
32MB
COM port RS-232C(2ch) COM1(16550, 9-pin D-SUB)
COM2(16550, 9-pin D-SUB, Settable for RS-422/485)
LAN 10BASE-T/100 BASE-TX 1ch, NS DP83816A
PS/2 Keyboard I/F PS/2 type (6-pin MINI-DIN)
Capable of using both of keyboard and mouse with commercial PS/2 branch cable
PC card slots PCMCIA Type II×2, or TypeIII×1
General-purpose I/O Optocoupler isolated inputs and outputs: 3 channels each
USB 1ch(USB 1.1) <IPC-PT/MV10, IPC-PT/LS10 series>
2ch(USB 1.1) <HPC-HMV10, HPC-HLS10 series>
Output terminals for external
speakers
φ3.5 Stereo mini jack Full-scale output level 1.0Vrms(Typ.)
Front switch & Power LED Front switch input: 3 points; Front Power LED: 3-color display
Video input terminator *3 BNC connector. Input impedance 75Ω
<IPC-PT/MV10AC, HPC-HMV10AC>
100VAC
Input range: 100V~240VAC 50VA
<IPC-PT/LS10AC, HPC-HLS10AC>
100VAC
Input range: 100V~240VAC 50VA
<IPC-PT/MV10DC1, HPC-HMV10DC1>
+12VDC
Input range: 12V±5% 2.5A(Max.)
<IPC-PT/LS10DC1, HPC-HLS10DC1>
+12VDC
Input range: 12V±5% 2.5A(Max.)
Input power supply
<IPC-PT/MV10DC2, HPC-HMV10DC2>
+24VDC(insulation)
Input range: 20V~28VDC 2A(Max.)
<IPC-PT/LS10DC2, HPC-HLS10DC2>
+24VDC(insulation)
Input range: 20V~28VDC 2A(Max.)
Power supply 100VAC input type: 50VA (Max.)
12VDC input type: 12VDC±5% 2.5A(Max.)
24VDC input type: 24VDC ±20% 2A(Max.)
Outside dimensions (mm) 305(W)×240(H)×51(D) 316(W)×256(H)×54(D)
Panel cut dimensions (mm) 292(W)×227(H) 303(W)×243(H)
Weight About 3.3kg *1 About 3.5kg *1
*1 Does not include cables, optional accessories, and screws, etc.
*2 The number of times of rewriting is 300,000, MTBF=4,797,667hours(CF-CARD)
*3 As for a Video input terminal, only HPC-HMV10 and HPC-HLS10 series are carried.
