Physical Dimensions
IPC-PT/MV10 series, HPC-HMV10 series
305
106.6
107.6
86.774.7
240
51
5
46
226
98.3
(Maximum tapping length:10mm)
4-M4 TAP
75
291
82.5
48
16
16 30
50
7562
[mm]
The illustration above is of the IPC-PT/MV10 series but the check points are the same as with the HPC-HMV10 series.
Figure 2.3. Physical Dimensions < IPC-PT/MV10 series, HPC-HMV10 series >
IPC-PT/LS10 series, HPC-HLS10 series
316
249
95.7591.75
256
19 30
16
54
5
49
242
99.3
75
82.5
302
55.5
48
70 75
(Maximum tapping length:10mm)
4-M4 TAP
[mm]
The illustration above is of the IPC-PT/MV10 series but the check points are the same as with the HPC-HMV10 series.
Figure 2.4. Physical Dimensions < IPC-PT/LS10 series, HPC-HLS10 series >
