Contec IPC-PT/MV10 Series Hardware Manual

3. Each Component Function
IPC-PT/MV10 / IPC-PT/LS10 / HPC-HMV10 / HPC-HLS10 Hardware Manual 25
Setup of OS operation (SW2)
This switch sets OS operation. For details, refer to the software manual.
Default setting
12345678
ON
Default setting of DIP switch
Figure 3.17. Setup of OS operation
CAUTION
Use this setting for normal operation.
DIP switch for applications (SW3)
SW3 is a general-purpose switch available for use by the application. Refer to the software manual for
details on how to use this DIP switch.
1234
ON
Default setting
Default setting of DIP switch
Figure 3.18. General Switch
COM2 RS-422A/485 transfer mode setting DIP-SW (SW4)
See the above description of the serial port interface.
CAUTION
Operating a connector or jumper on the internal CPU board, which is not covered by this manual,
can cause the unit to malfunction or develop operational problems. Never touch any of those
on-board connectors and jumpers.
