Commander SE User Guide
Issue Number 5 9
Table 3.9 Commander SE Size 2, 400V Three phase units
* See section 3.1.1.
** For an explanation of inrush current, see section 3.1.2.
Table 3.10 Recommended fuses and cables
Table 3.11 Braking Resistors
Before fitting a braking resistor please read the information on Braking, and
the Warnings on High Temperatures and Overload Protection at the end of
this section.
MODEL SE23400...
075 110 150 220 300 400
AC supply voltage and frequency 3 phase 380 to 480V +/- 10%, 48 to 62Hz
Input displacement factor (cos φ)>0.97
Nominal motor power - kW 0.75 1.1 1.5 2.2 3.0 4.0
Nominal motor power - HP 1.0
2.0 3.0 5.0
Output voltage and frequency 3 phase, 0 to input voltage, 0 to 1000Hz
100% RMS output current - A 2.1 3.0 4.2 5.8 7.6 9.5
150% overload current for 60 secs - A 3.2 4.5 6.3 8.7 11.4 14.3
Typical full load input current - A*400V, 50Hz/480V, 60Hz 3.6 4.8 6.4 9.3 11 14
Typical inrush current - A** (duration <10ms) 90 60
Drive power losses at 480VAC at 6kHz switching
frequency - W 43 57 77 97 122 158
Weight - kg/lb 2.75 / 6
Cooling fan fitted No Yes
MODEL SE23400...
075 110 150 220 300 400
Recommended input supply fuse - A 10 16 20
Control cable mm² ≥ 0.5
AWG 20
Recommended input cable mm² 1.0 1.5 2.5
AWG 16 14 12
Recommended motor cable mm² 1.0 1.5
AWG 16 14
Recommended braking resistor cable mm² 1.5
AWG 14
MODEL SE23400...
075 110 150 220 300 400
Minimum braking resistor value - Ω 100 75
Recommended braking resistor value - Ω 200 100
Maximum braking current - A 10 12.5
Resistor peak power rating - kW 3.4 6.9
NOTE
