Commander SE User Guide
10 Issue Number 5
Table 3.12 Commander SE Size 3, 200V units
* See section 3.1.1.
** For an explanation of inrush current, see section 3.1.2.
Table 3.13 Recommended fuses and cables
Table 3.14 Braking Resistors
Before fitting a braking resistor please read the information on Braking, and
the Warnings on High Temperatures and Overload Protection at the end of
this section.
MODEL SE33200...
550 750
AC supply voltage and frequency 3 phase 200 to 240V +/-10%, 48 to 62Hz
Input displacement factor (cos φ) >0.97
Nominal motor power - kW 5.5 7.5
Nominal motor power - HP 7.5 10.0
Output voltage and frequency 3 phase, 0 to input voltage, 0 to 1000Hz
100% RMS output current - A 25.0 28.5
150% overload current for 60 secs - A 37.5 42.8
Typical full load input current - A* 22.8 24.6
Typical inrush current - A** (duration <10ms) 44
Drive power losses at 230VAC at 6kHz switching
frequency - W
230 305
Weight - kg/lb 6 / 13.2
Cooling fan fitted Yes
MODEL SE33200...
550 750
Recommended input supply fuse - A 30
Control cablemm² >
0.5
AWG 20
Recommended input cablemm² 4.0
AWG 10
Recommended motor cablemm² 4.0
AWG 10
Recommended braking resistor cablemm² 4.0
AWG 10
MODEL SE33200...
550 750
Minimum braking resistor value - Ω 11.0
Recommended braking resistor value - Ω 15.0
Maximum braking current - A 28.0
Resistor peak power rating - kW 11.8
NOTE
