Commander SE User Guide
34 Issue Number 5
The total current available from the +24V rail, which includes the digital
output, is 100mA. Therefore if the digital output is providing 30mA, the +24V
rail will only provide 70mA.
If the enable terminal is opened, the Drive’s output is disabled and the motor will coast to a stop.
The Drive cannot be re-enabled for 2 seconds following the opening of the enable terminal.
† Following a Drive trip, open and close the Enable terminal to reset the Drive. If the Run
Forward or Run Reverse terminal is closed, the Drive will run straight away.
* Following a Drive trip and a reset via the Stop/Reset key the Run Forward or Run Reverse
terminals will need to be opened and closed to allow the Drive to run. This ensures that the Drive
does not start when the Stop/Reset key is pressed.
Provide fuse or other over-current protection in status relay circuit.
8 Digital output
Function Zero Speed Output
Absolute maximum voltage range +35V to -1V with respect to 0V common
Voltage range 0V to +24V
Maximum output current 50mA at +24V
Output impedance 10kΩ pull-down resistor in inactive state.
Update time 1.5ms
Operation of digital output +24V = Zero speed, 0V = Above zero speed
NOTE
9
10
11
12
13
Digital input - Enable / Reset †
Digital input - Run Forward (Edge triggered) *
Digital input - Run Reverse (Edge triggered) *
Digital input - Local/Remote Speed Ref (A1/A2)
Digital input - Jog
Default Positive logic (See parameter 34)
Voltage range 0V to +24V
Absolute maximum voltage range +35V to -18V with respect to 0V common
Nominal threshold voltage +10V
Input impedance 7.5kΩ
Sample time 1.5ms
14 +24V output
Voltage accuracy ± 10%
Maximum output current 100mA
Protection tolerates continuous short circuit to 0V
15
16
Status relay (Normally open)
Function Drive Healthy
Voltage rating 240VAC /30VDC
Current rating 2A/6A (resistive)
Contact isolation
2.5kVAC (meets IEC664-1 with over voltage
category II)
Update time 6ms
Operation of contact
OPEN - AC supply removed from Drive
- AC supply applied to Drive with the Drive in a
tripped condition
CLOSED
- AC supply applied to Drive with the Drive in a
‘ready to run’ or ‘running’ condition (not tripped)
WARNING
