Page #48 background imageLoading...
Page #48 background image
Commander SE User Guide
44 Issue Number 5
L1 - Level 1 access - Only parameters 1 to 10 can be selected for viewing or adjusting.
L2 - Level 2 access - All parameters 1 to 44 can be selected for viewing or adjusting.
Loc - Used to lock a security code in the Drive. See Security codes in Section 6.5.
6.10.3Level 2 parameters
Defines the preset speed 1.
For setting of negative preset speed values, see parameter 17.
Defines the preset speed 2.
For setting of negative preset speed values, see parameter 17.
Defines the preset speed 3.
For setting of negative preset speed values, see parameter 17.
Defines the preset speed 4.
For setting of negative preset speed values, see parameter 17.
Defines the jog speed.
Defines the current input on Analog input reference 2, terminal 5. Definition of the
current input mode is given in the following sub-table:
No. Function Type Limitations Range Units Defaults
10
Parameter
access
RW T L1, L2, Loc L1 EUR
L1 USA
No. Function Type Limitations Range Units Defaults
11
Preset 1 RW B ±1000.0 Hz 0.0 EUR
0.0 USA
No. Function Type Limitations Range Units Defaults
12
Preset 2 RW B ±1000.0 Hz 0.0 EUR
0.0 USA
No. Function Type Limitations Range Units Defaults
13
Preset 3 RW B ±1000.0 Hz 0.0 EUR
0.0 USA
No. Function Type Limitations Range Units Defaults
14
Preset 4 RW B ±1000.0 Hz 0.0 EUR
0.0 USA
No. Function Type Limitations Range Units Defaults
15
Jog
reference
RW U 0 - 400.0 Hz 1.5 EUR
1.5 USA
No. Function Type Limitations Range Units Defaults
16
Current
input
mode
RW T 0-20, 20-0
4-20, 20-4
4-.20, 20-.4
mA 4-.20 EUR
4-.20 USA
Mode Description
0 - 20 Current input 0 to 20mA (20mA full scale)
20 - 0 Current input 20mA to 0mA (0mA full scale)
4 - 20 Current input 4mA to 20mA with current loop loss (cL) trip (20mA full scale)
20 - 4 Current input 20mA to 4mA with current loop loss (cL) trip (4mA full scale)
4 - .20 Current input 4mA to 20mA with no current loop loss (cL) trip (20mA full scale)
20 - .4 Current input 20mA to 4mA with no current loop loss (cL) trip (4mA full scale)
