M’Ax User Guide 49
Issue Number: 4
0.49 indicates the state of security as shown below (the displayed digits
are treated as individual digits; they do not create a three-digit number):
See Chapter 7 Security and Accessing the Advanced Parameters.
Default settings
Use parameter 0.50 to initiate the transfer of parameter values between
the RAM, EEPROM (when an option module is fitted), and the flash
memory in the Drive (see Appendix H Storage and Transfer of
Parameter Values). After changing the setting of parameter
0.50,
perform either of the following, as appropriate:
• While the display is in Edit mode, press at the same time:
• Set 10.38 at 100 via serial communications.
Terminology
Notes
At the time of selecting no, boot1 or boot2, all parameter values
(including the S-parameters) are copied to the flash memory (store).
All parameters can be stored at any time by setting
11.67 Flash update
enable at
1. The Drive must not be powered-down within 15 seconds.
When S-parameters are not copied, the related values at the destination
remain unchanged.
Main parameters can be saved irrespective of the setting of parameter
0.50 (i.e. by setting parameter XX.00 at 1000 and executing the
operation).
0.49
Security status indicator
ô
000 ~ 111
RO Uni
Digit 1
Value Indicates...
0 Standard security is unlocked
1 Standard security is locked
Digit 2
Value Indicates...
0 Standard security is unlocked
1 Standard security is locked
Digit 3
Value Indicates...
0 Usersecurityisnotsetup
1 A User security number has been entered into
0.35
0.50
Parameter transfer selector
ô
(see below)
RW Txt
Version Setting
AN no
SL boot2
Save
Copy main-parameter values in the RAM to the
EEPROM (when an option module is fitted)
Retrieve
Copy all parameter values from the EEPROM to
theRAM(whenanoptionmoduleisfitted)
Store
Copy parameter values from the RAM to the flash
memory in the Drive
Restore
Copy parameter values from the flash memory to
the RAM
Main parameters
All parameters other than those that are normally
saved or stored at power-down
S-parameters
Parameters that are normally saved at power-down
(version _
AN only)
and
Setting Function Usage
no
0
At power-down: S-
parameter values are copied
from the RAM to the
EEPROM (save).
At power up: All parameter
values are copied from the
EEPROM to the RAM
(retrieve).
Used only when an
option module is fitted
(normally, in version
_
AN)
rEAd 1
The main-parameter values
in the flash memory are
immediately copied to the
RAM (restore).
Normally used in
version _
SL,butcan
also be used in version
_
AN
Prog
2
The main-parameter values
in the RAM are immediately
copied to the flash memory
(store).
boot1 3
At power-up: The main-
parameter values in the
flash memory are copied to
the RAM (restore). The
values of
the S-parameters are
ignored.
boot2 4
At power-up: All parameter
values (including the S-
parameters) in the flash
memoryarecopiedtothe
RAM (restore).
