Control Techniques Profibus-DP - 8 Diagnostics; Fieldbus Code; Firmware Version

Issue Number: 3 35
8 Diagnostics
NOTE
The information from the parameters described below should always
be noted before contacting Control Techniques for technical support.
8.1 Fieldbus Code
Unidrive: #20.14
The fieldbus code identifies the hardware level in the Profibus-DP
interface. This information is vital when trying to determine what
upgrades can be performed on older modules.
The identification of the high-speed communications option module can
be read from #20.14 on the Unidrive display. This number is shown in
the form XYZ, where X is the fieldbus type, Y is the fieldbus flavour, and
Z is the hardware revision level.
#20.14 Fieldbus
Type
Fieldbus
Flavour
Hardware Revision
100 1
(Profibus)
0
(DP)
0
(UD73A Issue 1 and UD73B Issue 1)
8.2 Firmware Version
Unidrive: #20.15
The version of firmware fitted to the Profibus-DP interface can be read
from #20.15. The Hardware Revision column shows the hardware
levels that can accept each version of firmware.
#20.15 Firmware
Version
Hardware
Revision
202 V2.02.00 0
204 V2.04.00 0
205 V2.05.00 0
