10 Quick Reference
10.1 Complete Parameter Reference
Parameter Default Description
#20.01 121 OUT Channel 2 Mapping
#20.02 408 OUT Channel 3 Mapping
#20.03 201 IN Channel 2 Mapping
#20.04 402 IN Channel 3 Mapping
#20.05 0 Node Address
#20.06 9011 OUT Channel 1 Mapping
#20.07 9011 IN Channel 1 Mapping
#20.11 48 Trip Delay Time (ms)
#20.13 0 Data Endian Format
#20.14 ---- Option ID Code (Read only)
#20.15 ---- Firmware Version XXYY, where the firmware
version is VXX.YY.ZZ (Read only)
#20.50 ---- Fieldbus Diagnostic (Read only)
#17.02 ---- System File Version (Read only)
#17.14 0 Network Loss Trip Enable
#17.19 0 UD70 Store and Reset
#20.08 0 Reserved
#20.09 0 Reserved
#20.10 0 Reserved
#20.12 0 Reserved
#20.16 0 Reserved
#20.17 0 Reserved
#20.18 0 Reserved
#20.19 0 Reserved
#20.20 0 Reserved
10.2 Profibus-DP Data Formats
Non-cyclic
mode
Cyclic
words
Consistency Comments
1 3 Full
1 3 None
These modes are supported by
Mentor II and Commander SE
1 3 Full 8 bytes with full consistency,
available for backwards
compatibility with older modules
