CONVAID USER’S GUIDE
Planar Positioning Options
H-harness with Padded Covers
H-harness shoulder straps help the user retain upright trunk position. To reposition the
H-harness:
Remove the Planar Back from chair. Remove the H-harness by unscrewing it from the
back.
Fig. 117 Reposition the H-harness straps by placing the screw through the grommet
hole on each strap and screwing it into the appropriate hole on the planar back. Bring the
straps to the front of the planar back, threading between sections if necessary. Reattach
the planar back to the chair. Make any necessary adjustments to the height of the
H-harness straps by moving the plastic slider up or down. After all adjustments are made,
attach the H-harness to the three point positioning belt with the spring snaphook at the
end of the H-harness. Fig. 118
Note: Velour-covered
shoulder pads for the
H-harness are standard.
Fig.117
Fig.118
