Converteam MVS3007 - Specifications; Specification; PROFIBUS Board Specification; Fieldbus

ALSPA PROFIBUS Field Bus Coupler 2. Specification
(09/06) Technical Manual Page 2-1
2. Specification
2.1 PROFIBUS Board Specification
2.1.1 Fieldbus
Capable of communication rates from 9600 bit/s to 12Mbit/s (1.5M
bits/s for MVS3007-4001 PROFIBUS board).
Automatic Baud rate
1
selection from the following list:
• 9,600 bits/s
• 19,200 bits/s
• 93,750 bits/s
• 187,500 bits/s
• 500K bits/s
• 1.5M bits/s
• 3M bits/s (MVS3007-4002 PROFIBUS board only)
• 6M bits/s (MVS3007-4002 PROFIBUS board only)
• 12M bits/s (MVS3007-4002 PROFIBUS board only)
2.1.2 PROFIBUS Protocol
Implements the PROFIBUS-DP Fieldbus protocol according to DIN
19245.
2.1.3 Data Refresh Rate
Data is exchanged between the PROFIBUS Fieldbus module and
the drive's parameters every 10ms.
2.1.4 MVS3007-4001 board Data Volume
Cyclic Channel Receive:
• 1 control word (16 bit), and
• 5 reference demands (16 bit),
or,
• 2 control words (16 bit), and
• 4 reference demands. (16 bit).
1
If at any time the baud rate is changed in the PROFIBUS-DP master then it is
necessary to power cycle the drive for the change to be recognised by this module.
