ALSPA PROFIBUS Field Bus Coupler 8. Menu 75 Parameters
(09/06) Technical Manual Page 8-11
8.6 Fieldbus Configuration Menu
Table 8-7 Menu 75
Par No Description Default Range Attr. Comment
75.00 Expansion bus device Set by
hard-
ware
3 = Fieldbus Coupler R See page 8-2
75.01 Protocol ID 0 Reserved for future use R Not used
75.02 Node Address
6
255 0 to 127 (4002: 0 to 255) E See page 8-2
75.03 Protocol 3 4002= 2 or 3
4001 FIXED= 3
E.L See page 8-2
75.04 Automatic configuration
at power up
0 0= Prevent, 1 = Allow E.L See page 7-3
75.05 Configure Link 0 1 to configure. Automatically
reset to 0 by a configuration
attempt.
E.L See page
8-3
75.06 Action on loss of
PROFIBUS control
source.
1 0 = Ignore
1 = Warning
2 = Trip
E.L See page
8-3
75.07 Freeze / Fallback 1 0 = Freeze
1 = Fallback
E.S.L
See page 8-4
75.08 Control Word 1 0 0 – FFFF R See page 8-4
75.09 Control Fallback 1 0 0 – FFFF E See page 8-4
75.10 Control Word 2 0 0 – FFFF R See page 8-4
75.11 Control Fallback 2 0 0 – FFFF E See page 8-4
75.12 Reference 1 0
±100.00
E See page 8-5
75.13 Fallback 1 0
±100.00
E See page 8-5
75.14 Reference 2 0
±100.00
E See page 8-5
75.15 Fallback 2 0
±100.00
E See page 8-5
75.16 Reference 3 0
±100.00
E See page 8-5
75.17 Fallback 3 0
±100.00
E See page 8-5
75.18 Reference 4 0
±100.00
E See page 8-5
75.19 Fallback 4 0
±100.00
E See page 8-5
75.20 Reference 5 0
±100.00
E See page 8-5
75.21 Fallback 5 0
±100.00
E See page 8-5
75.22 CW 1 Pointer 0 0 - 99.99 E.S.N See page 8-5
75.23 Ref. 1 Pointer 0 0 - 99.99 E.S.N See page 8-5
75.24 Ref. 2 Pointer 0 0 - 99.99 E.S.N See page 8-5
75.25 Ref. 3 Pointer 0 0 - 99.99 E.S.N See page 8-5
75.26 Ref. 4 Pointer 0 0 - 99.99 E.S.N See page 8-5
75.27 CW 2/Ref. 5 Pointer 0 0 - 99.99 E.S.N See page 8-5
75.28 Value for 100% Ref. 10000
0 ±32767
E See page 8-8
75.29 Scale Reference Mask 001Eh 0-FFFFh E.S See page 8-8
75.30 Status word Source 0 0 - 99.99 E.S.N See page 8-6
75.31 Value 1 Source 0 0 - 99.99 E.S.N See page 8-6
75.32 Value 2 Source 0 0 - 99.99 E.S.N See page 8-6
6
This parameter requires a PROFIBUS reconfiguration before changes can take
effect.
