7.5 Scale Menu 60 Description
This menu allows the scaling between drive and Fieldbus to be
specified for various different data types.
A pair of parameters specifies each scale. The first parameter
specifies the drive value equivalent to the external Fieldbus value
contained in the second parameter of the pair. For example, if the
drive represents a value of 100% by the value 10000 and the
Fieldbus represent 100% by the value 16383, the first parameter
will contain 10000 and the second parameter will contain 16383.
When a parameter is to be output to the Fieldbus using the scale
detailed in the above example the formula is:
When receiving a parameter from the Fieldbus the formula is:
Table 7-6 lists the data types that have been provided.
Table 7-6 Data Types
Data Type Parameter
Speed(%) P60.00 and P60.01
Speed(rpm) P60.02 and P60.03
Torque(%) P60.04 and P60.05
Torque(Nm) P60.06 and P60.07
Frequency P60.08 and P60.09
Percent P60.10 and P60.11
Speed Ramp Rate P60.12 and P60.13
Torque Slew Rate P60.14 and P60.15
Current P60.16 and P60.17
Volts P60.18 and P60.19
Resistance P60.20 and P60.21
Inductance P60.22 and P60.23
User scaler 1 P60.24 and P60.25
User scaler 2 P60.26 and P60.27
User scaler 3 P60.28 and P60.29
Note: Table 7-7 includes a full list of Menu 60 parameters
alentValueDriveEquiv
lueuivalentVaExternalEq
alueParameterVOutput ×=
lueuivalentVaExternalEq
alentValueDriveEquiv
InputalueParameterV ×=
