Converteam MVS3007 - FBC 1 Config Menu 74

ALSPA PROFIBUS Field Bus Coupler 7. Menu 74 Parameters
(09/06) Technical Manual Page 7-11
7.4.16 FBC 1 Config Menu 74
Table 7-5 FBC 1 Config Menu 74
Par No Name Default Range Attrib. Comment
P74 FBC 1 Config Menu
P74.00 Expansionn Bus Device Monitor 3=Fieldbus Coupler R
P74.01 FBC1 Protocol 3 3=PROFIBUS-DP Slave E.L.N.S
P74.02 FBC1 Node Address 0 0 .. 127 E 1..127 for
PROFIBUS
P74.03 FBC1 PPO Type 4 0=DiL switch
1=PPO Type 1
2=PPO Type 2
3=PPO Type 3
4= PPO Type 4
5= PPO Type 5
E.L Option 0 for
MVS3007-
4001 boards
only.
P74.04 Auto Config. FBC1 0 0=Disable
1=Enable
E.L.N
P74.05 Configure FBC1 0 0=Disable
1=Enable
E.L.N
P74.06 Use FBC1 Data. 1 0=Disable
1=Enable
E.L
P74.07 Ref. Loss Action 1 0=Ignore
1=Set Warning Bit
2=Trip Drive
E.L
P74.08 FBC1 Fallback Action 1 0= Freeze
1= Fallback
E.L.S
P74.09 FBC1 Comms. Status Monitor 0=On-line
1=Not configured
2=Network not found
3=Not communicating
4=Unknown Protocol
5=Promptness Error
6=Freshness Error
7=Synchronize Error
8=Config. Fault
9=Internal FBK Error
10=Sched. Build Error
11=FBK Scaling Fault
12=Drive Fault
R
P74.10 FBC1 Tx Error Word Monitor 0000 to FFFFhex R.
P74.11 FBC1 Tx Error Count Monitor 0-65535 R
P74.12 FBC1 Rx Error Word Monitor 0000 to FFFFhex R.
P74.13 FBC1 Rx Error Count Monitor 0-65535 R
P74.20 FBC1 Reference 1 0
±200.00 %
E
P74.21 FBC1 Ref. 1 Fallback 0
±200.00 %
E
P74.22 FBC1 Reference 2 0
±200.00 %
E
P74.23 FBC1 Ref. 2 Fallback 0
±200.00 %
E
P74.24 FBC1 Reference 3 0
±200.00 %
E
P74.25 FBC1 Ref. 3 Fallback 0
±200.00 %
E
P74.26 FBC1 Reference 4 0
±200.00 %
E
P74.27 FBC1 Ref. 4 Fallback 0
±200.00 %
E
P74.28 FBC1 Reference 5 0
±200.00 %
E
