ALSPA PROFIBUS Field Bus Coupler 7. Menu 74 Parameters
(09/06) Technical Manual Page 7-9
PROFIBUS network to represent 100%. The default scale is set to
unity.
7.4.15 Transmitted Data, P74.70 to P74.89
To put data into the transmit PPO, it must be taken from
somewhere within the drive. Parameters P74.70 to P74.89 allow
the relevant PPO word to be allocated. See Table 7-3.
Table 7-3 Transmitted PPO data mapping example for PPO type 4
Parameter Value Meaning
Example
P74.72 P9.01 = PPO PZD2 (Speed feedback)
P74.73 1 = Speed (%) scaler
P74.70 P(0-99.99) = PPO PZD1
P74.71 0 to 15 = Scaler (0 = unity)
P74.72 P(0-99.99) = PPO PZD2
P74.73 0 to 15 = Scaler (0 = unity)
P74.74 P(0-99.99) = PPO PZD3
P74.75 0 to 15 = Scaler (0 = unity)
P74.76 P(0-99.99) = PPO PZD4
P74.77 0 to 15 = Scaler (0 = unity)
P74.78 P(0-99.99) = PPO PZD5
P74.78 0 to 15 = Scaler (0 = unity)
P74.80 P(0-99.99) = PPO PZD6
P74.81 0 to 15 = Scaler (0 = unity)
The PROFIDRIVE standard specifies that PZD1 (ZSW) contain a
status word following the definition in
Table 7-4. The
Programmable Status Word in P41.32 or P41.33 is a collection of
status bits specified by parameters P41.00 to P41.15, or P41.16 to
P41.31. These can be used to set up the status word required by
PROFIDRIVE, and then point P74.30 to P41.32 or P41.33.
