ALSPA PROFIBUS Field Bus Coupler 7. Menu 74 Parameters
(09/06) Technical Manual Page 7-15
7.5.1 Scaling Parameter Menu 60
Table 7-7 Scaling Parameter Menu 60
Par No Name Default Range Attrib. Comment
P60.00 Drive Speed (%) 10000
±32,767 pu %
E.N
P60.01 Extern Speed (%) 10000
±32,767 pu %
E.N
P60.02 Drive Speed (rpm) 1000
±32,767 pu rpm
E.N
P60.03 Extern Speed (rpm) 1000
±32,767 pu rpm
E.N
P60.04 Drive Torque (%) 10000
±32,767 pu %
E.N
P60.05 Extern Torque (%) 10000
±32,767 pu %
E.N
P60.06 Drive Torque (Nm) 10000
±32,767 pu Nm
E.N
P60.07 Extern Torque (Nm) 10000
±32,767 pu Nm
E.N
P60.08 Drive Frequency 100
±32,767 pu Hz
E.N
P60.09 Extern Frequency 1
±32,767 pu Hz
E.N
P60.10 Drive Percent 10000
±32,767 pu %
E.N
P60.11 Extern Percent 10000
±32,767 pu %
E.N
P60.12 Drive Ramp Rate 10000
±32,767 pu/s
E.N
P60.13 Extern Ramp Rate 10000
±32,767 pu/s
E.N
P60.14 Drive Torque Rate 10000
±32,767 pu/s
E.N
P60.15 Extern Torque rate 10000
±32,767 pu/s
E.N
P60.16 Drive Current 10
±32,767 pu A
E.N
P60.17 Extern Current 1
±32,767 pu A
E.N
P60.18 Drive Volts 1
±32,767 pu V
E.N
P60.19 Extern Volts 1
±32,767 pu V
E.N
P60.20 Drive Resistance 1
±32,767 pu Ω
E.N
P60.21 Extern Resistance 1
±32,767 pu Ω
E.N
P60.22 Drive Inductance 1
±32,767 pu H
E.N
P60.23 Extern Inductance 1
±32,767 pu H
E.N
P60.24 Drive Scalar 1 1
±32,767 pu
E.N
P60.25 Extern Scalar 1 1
±32,767 pu
E.N
P60.26 Drive Scalar 2 1
±32,767 pu
E.N
P60.27 Extern Scalar 2 1
±32,767 pu
E.N
P60.28 Drive Scalar 3 1
±32,767 pu
E.N
P60.29 Extern Scalar 3 1
±32,767 pu
E.N
7.6 Data Spy Parameters P89.00 to P89.10
The Data Spy parameters can be used to help debug and
commission the PROFIBUS network as well as monitoring data
transactions during normal operation. Using the spy area of Menu
89 it is possible to monitor data received by the module, in its
unmodified form. The data is available in parameters P89.01 to
P89.10 and corresponds to the PZD of the PPO of interest.
