ALSPA PROFIBUS Field Bus Coupler 3. Installation
(09/06) Technical Manual Page 3-3
3.3.1 Location of Switches
96-way connector
X1
X2
PE1
S3
S2
Figure 3-2 MVS3007-4001 PROFIBUS Layout
