ALSPA PROFIBUS Field Bus Coupler 3. Installation
(09/06) Technical Manual Page 3-7
3.4.2 Location of Switch S2
96-way connector
X1
X210
PE1
S2
Figure 3-4 MVS3007-4002 PROFIBUS Layout
