7. Menu 74 Parameters ALSPA PROFIBUS Field Bus Coupler
Page 7-16 Technical Manual (09/06)
The values are displayed in decimal with no scaling and should be
exactly what is appearing on the PROFIBUS network.
To select a PPO to be spied upon, enter the parameter number as
listed in
Table 7-8.
Table 7-8 Data Spy Menu 89
PPO Active Menu P89.00 Value Meaning
Fbus RX PPO Menu 75 75.00 to 75.29
Spy Receive PPO
Fbus TX PPO Menu 75 75.30 to 75.46
Spy Transmit PPO
FBC1 RX PPO Menu 74 74.50 to 74.69
Spy Receive PPO
FBC1 TX PPO Menu 74 74.70 to 74.89
Spy Transmit PPO
