Appendix B. Configuration Tables ALSPA PROFIBUS Field Bus Coupler
Page B8 Technical Manual (09/06)
14 P41.30
15 P41.31
Table B-8 Menu 42 - Reference Pointers
No. Param. Points
To
Param.
Scale Function
Example
1 P42.00 75.12 10000 Speed Reference
1 P42.00 Speed Reference
2 P42.02 Speed Reference
3 P42.04 Reference Sequencer
4 P42.06 PID Set-point
5 P42.08 PID Feedback
6 P42.10 Trim Reference
7 P42.12 Speed Trim Reference
8 P42.14 Torque Reference
9 P42.16 Torque Limits
10 P42.18 Torque Limits
11 P42.20 Temperature Compensation Scale
12 P42.22 Flux Limit
13 P42.24 Current Limit
14 P42.26 Torque/Magnet. Current
15 P42.28 Torque/Magnet. Current
16 P42.30 Position Reference
17 P42.32 Position Reference
18 P42.34 Tacho Feedback
