Introduction
Service Information S280-70-3 provides installation and
operation instructions for the Form 6 pole-mount recloser
control above serial number 10,000 or beginning with
CP57.
Refer to the following information as appropriate for your
version of ProView software:
• Service Information S280-70-4 Form 6 Recloser Control
Programming Guide: ProView 4.X.X software
• Service Information S280-70-21 Form 6 Recloser
Control Programming Guide: ProView 5.X.X software
Read This Manual First
Read and understand the contents of this manual and
follow all locally approved procedures and safety practices
before installing or operating this equipment.
Additional Information
These instructions cannot cover all details or vari ations in
the equipment, procedures, or process described, nor
provide directions for meeting every possible contin gency
during installation, operation, or maintenance. When
additional information is desired to satisfy a problem not
cov ered sufficiently for the user's purpose, contact your
Cooper Power Systems sales representative.
ANSI Standards
Kyle reclosers are designed and tested in accordance with
the following ANSI standards: C37.60 and C37.85 and
ANSI Guide C37.61.
Quality Standards
ISO 9001-Certified Quality Management System
Acceptance and Initial Inspection
Each Form 6 recloser control is completely assembled,
tested, and inspected at the factory. It is carefully calibrated,
adjusted and in good condition when accepted by the
carrier for shipment.
Upon receipt, inspect the carton for signs of damage.
Unpack the control and inspect it thoroughly for damage
incurred during shipment. If damage is discovered, file a
claim with the carrier immediately.
Handling and Storage
Be careful during handling and storage of the control to
minimize the possibility of damage. If the control is to be
stored for any length of time prior to installation, provide a
clean, dry storage area. If storage is in a humid atmosphere,
make provisions to keep the control circuitry energized.
Note: To energize the control, apply AC power to the AC supply
input terminal block located in the lower right hand
corner of the back panel of the control. Refer to the
Customer Connections for AC Power section in this
manual.
Control Battery Storage and Charging
The 24 VDC control battery in the Form 6 recloser control is
fully charged prior to shipment and is ready for use.
Temperature has an effect on battery life. Sealed lead acid
batteries should be stored, fully charged, at room
temperature. Never store lead acid batteries at temperatures
exceeding 47°C (117°F), as damage can result in
approximately one month.
The batteries must be tested and charged for 24 hours
following every three months of storage from the last test
date. A separate portable charger accessory is available.
Catalog Number KA43ME7001 provides a 120 Volt battery
charger to power individual batteries.
Note: When shipped from the factory, the battery source is
disconnected and its output plugs are taped to the
cabinet. Connect the battery plugs into the mating
connectors to complete the battery circuit.
Control Power
The control is powered from 120 or 240 VAC. The selector
switch on the power supply board allows the user to select
between 120 VAC or 240 VAC.
Note: The selector switch is factory-set for each control based
upon the customer order requirement.
Battery Replacement and Disposal
The 24 VDC control battery has a life expectancy of four
years. It is recommended that the battery be replaced after
four years or if the battery fails a battery test - whichever
occurs first.
Note: Battery life is decreased at higher temperatures.
Dispose expired batteries in an environmentally responsible
manner. Consult local regulations for proper battery
disposal.
S280-70-3
3
PRODUCT INFORMATION
IMPORTANT: To maintain sufficient charge to operate
the control and prevent battery cell damage, the sealed
lead-acid batteries should be charged after no more
than three months of storage.
IMPORTANT: Connect the control battery before ac
power is connected to the control’s AC supply Input
Terminal Block. The battery must be disconnected prior
to shipping or storing the control.
