The Form 6 recloser control can be used with the old-style
Type A CTs; however, the event recorder and duty cycle
monitor will have limited accuracy for currents above 5000
Amps.
Retrofit kits with the new Type B sensing CTs are
available to upgrade existing families of reclosers for
operation with Form 6 recloser controls. For additional
information, contact your Cooper Power Systems
representative.
For identification, Table 1 lists the serial number breaks
between old-style Type A and the new-style Type B sensing
CTs. Below this serial number, the recloser is equipped
with the Type A CTs.
Note: For reclosers shipped prior to June 1989 and not listed
below, please contact your Cooper Power Systems
representative with the recloser type and serial number
for verification of type A or B bushing current
transformers.
Duty Cycle Monitor
The Duty Cycle Monitor provides the following duty cycle
information:
• Measures and records duty for each individual phase in
non-volatile memory.
• The recloser duty is measured and stored on the basis
of Current
1.5
x Number of Operations for Each Phase
(ANSI C37.61).
• Readout is based on a percentage of total duty cycle
for each phase.
• Duty record can be adjusted or reset if recloser is
changed-out, serviced, etc.
Using Table 2, select the appropriate recloser interrupting
duty cycle factor and enter that value via the ProView
interface software.
Mounting the Control
Mount the Form 6 pole-mount recloser control in a
convenient, accessible location. Mounting dimensions are
provided in Figure 10.
Note: Unless otherwise specified, dimensions shown in mm
(inches).
A hole and keyway in the control mounting bracket accom-
modates a 15.9 mm (5/8”) bolt.
Locking the Control
The handles on the Form 6 control cabinet are able to
accept a padlock to prevent unauthorized access. For
cabinets with the quarter-turn latch, the top handle has two
locking holes provided depending on the diameter of the
lock shackle being used. Refer to Figure 10.
• Use the smaller hole for shackle diameters of .177-
295”.
• Use the larger hole for shackle diameters of .295-.394”.
Note: DO NOT use a smaller shackle (.177-.295) in the
larger diameter hole as it will NOT LOCK the cabinet.
Form 6 Microprocessor-Based Pole-mount Recloser Control Installation and Operation Instructions
16
TABLE 2
Duty Cycle Factor
Interrupting 100% Duty
Recloser Rating Cycle
Type (rms sym Amps) Factor*
RXE, RVE 6,000 97
WE 12,000 @ 4.8 kV 257
WE 10,000 @ 14.4 kV 196
VWE
VWVE27 12,000 1045
VWVE38X
WVE27 8,000 140
WVE38X 8,000 140
VSA12 12,000 1045
VSA16 16,000 1608
VSA20
VSA20A 20,000 2248
VSA20B
VSO12 12,000 1045
VSO16 16,000 1608
Auxiliary-Powered
NOVA 12,500 1111
Control-Powered
NOVA 12,500 1111
*Duty Cycle Factor is Value x 10
5
.
TABLE 1
Serial Number Break for Reclosers with Type A
Sensing CTs
Recloser Below Serial Number
RXE 5831
RVE 5894
WE 11199
WVE 3695
VWE 7199
VWVE27 7208
VWVE38 1204
All VSA reclosers are equipped with Type A Sensing CTs.
All VSML reclosers are equipped with Type A Sensing CTs.
All VSA12, VSA12B, VSA16, VSA20, VSA20A, and VSA20B
reclosers are equipped with Type B Sensing CTs.
All VWVE38X and VWE38X reclosers are equipped with Type B
Sensing CTs.
WARNING: This equipment is not intended to
protect human life. Follow all locally approved pro-
cedures and safety practices when installing or operating
this equipment. Failure to comply may result in death,
severe personal injury and equipment damage. G102.1
CAUTION: Follow all locally approved safety practices
when lifting and mounting the equipment. Use the lifting
lugs provided. Lift the unit smoothly and do not allow the
unit to shift. Improper lifting can result in equipment
damage. G106.2
