Cooper Power Systems Form 6 Series - Page 17

S280-70-3
17
Figure 10.
Form 6 pole-mount recloser control weight, dimensions, and pad-lock shackle diameters.
Front View
710
(28.0)
310
(12.25)
Vent
Bottom View
Vent
1.44 Dia. Hole for
Voltage Input Connection
(Caplug Installed)
Mounting Angle
Control Cable
Receptacle
(14-pin or 19-pin)
1.44 Dia. Hole
(Caplug Installed)
1.44 Dia. Hole for
Low Voltage Closing
Connection
(Caplug Installed)
67
(2.75)
38
(1.5)
67
(2.75)
79
(3.25)
RS-232
Connection
Port
29
(1.25)
CONTROL POWER
CONTROL OK
CONTROL LOCKOUT
RECLOSER OPEN
RECLOSER CLOSED
A PHASE FAULT
B PHASE FAULT
C PHASE FAULT
GROUND FAULT
SENSITIVE GND
ALARM
ABOVE MIN TRIP
INDICATOR 1
INDICATOR 2
INDICATOR 3
A PHASE VOLTAGE
B PHASE VOLTAGE
C PHASE VOLTAGE
FREQUENCY TRIP
VOLTAGE TRIP
METERING
RESET
TARGETS
EVENTS
LAMP TEST
MENU
ENTER
+
—
SETTINGS
OPER
COUNTER
ALARMS
CHANGE
F1 F2 F3 F4
TRIP CLOSE
HOT LINE TAG
ON
GND TRIP
BLOCKED
NON
RECLOSING
SUPERVISORY
OFF
ALTERNATIVE
PROFILE #1
ALTERNATIVE
PROFILE #2
ALTERNATIVE
PROFILE #3
RS-232 DATA PORT
OPTION #1
OPTION #2
OPTION #3
(LOCKOUT)
INDICATOR 4
INDICATOR 5
INDICATOR 6
INDICATOR 7
INDICATOR 8
CLOSE CIRCUIT
DISABLE
CONTROL WEIGHT 34 kg (75 lbs)
170
(6.75)
355 (14.0)
400 (15.75)
16 (.63) Dia.
Mounting Holes (2)
Grounding
Terminal
#14 To #4
Stranded
665
(26.25)
Right Side View
Lifting
Lugs
SHACKLE DIAMETER
.177-295"
SHACKLE DIAMETER
.295-.394"
Note: DO NOT use a smaller shackle (.177-
.295) in the larger diameter hole as it
will NOT LOCK the cabinet.
