Before Placing the Control and the
Recloser into Service
Prior to placing the control and recloser into service, the
following installation procedures must be properly
completed and verified:
1. Front panel label inserts changed (if applicable).
Note: Refer to Using Removable Inserts in this manual.
2. Control properly mounted for the installation.
3. Recloser installed according to all locally approved
standards and practices.
4. AC disconnect switches installed.
5. Control and recloser properly grounded in accordance
with guidelines in this manual and the applicable
recloser manual.
6. Control cable properly connected and supported.
7. Verify the selector switch on the Power Supply/Battery
Charger Board is set to the correct position based
upon the incoming power supply:
• For 120 VAC incoming power, the selector switch
must be set to the 115V position.
• For 240 VAC incoming power, the selector switch
must be set to the 230V position.
8. Control battery connected and tested for proper
operation.
Note: The battery test is blocked for 30 seconds upon
power-up of the control.
Test the battery as follows:
A. Press the MENU button on the front panel.
B. Using the down arrow key, navigate to the BATTERY
menu and press ENTER.
C. Using the down arrow key, navigate to the TEST
BATTERY menu and press ENTER.
D. Press the F4 button to test the battery.
Note: This message will appear on the programming
panel LCD display: ----TESTING----
The battery test results will display in the battery
metering menu.
Note: With AC disconnected and the battery supplying
the load, current will read -400 to -600 mA
depending on accessories connected.
9. AC power connected to the control. (Control OK LED
indicator is illuminated.)
Note: The control Power Save feature will turn off the back-
lit LCD display and all LEDs if no front panel keypad
is pressed within ten minutes.
10. All control programming entered and verified by
appropriate personnel.
Note: Refer to Service Information S280-70-4 (ProView
4.X.X) or S280-70-21 (ProView 5.X.X) Form 6
Microprocessor-Based Recloser Control
Programming Guide for additional information.
11. Control clock set to the correct time.
Note: Refer to Service Information S280-70-4 (ProView
4.X.X) or S280-70-21 (ProView 5.X.X) Form 6
Microprocessor-Based Recloser Control
Programming Guide for additional information.
12. Customer connections for remote and supervisory
operation checked and completed in accordance with
proper shielding and surge protection (Figure 22).
NOTICE: External leads must be shielded and the shield
must be grounded at both ends. Terminate each lead with
a 320VAC, 150 Joules metal oxide varistor (MOV), or
equivalent, at the remote end. Attach MOV’s between the
leads and ground. Failure to properly shield and protect
leads can result in equipment damage and/or unintentional
operation.
Form 6 Microprocessor-Based Pole-mount Recloser Control Installation and Operation Instructions
30
CAUTION: Equipment misoperation. Do not
connect this control to an energized recloser until
all control settings have been properly programmed and
verified. Refer to the programming information for this
control. Failure to comply can result in control and
recloser misoperation, equipment damage, and personal
injury. G110.3
CAUTION: Equipment misoperation. Verify that
the 120/240 VAC selector switch is correctly set
for incoming voltage. Failure to comply may cause
misoperation (unintentional operation) of the control and/
or equipment damage resulting in personal injury.
T278.0
