Cooper Power Systems Form 6 Series User Manual

These accessories are available. Contact your Cooper
Power Systems representative for additional information.
Low Voltage Closing
The Low Voltage Closing Accessory utilizes 120 or 240
VAC for closing power (Figures 27, 28, 29, 30, and 31).
Multiple low voltage closing accessories are available for
reclosers equipped with low voltage closing. The low
voltage closing accessories available for the Form 6
recloser control include the appropriate receptacles and
wiring based upon the input supply voltage. Table 8 lists
the available low voltage closing input/output receptacles
and cables for the Form 6 pole-mount recloser control.
Internal Voltage Sensing
A four-wire cable and input receptacle accessory (Table 9)
is required for Type NOVA three-phase reclosers with the
internal voltage sensing (IVS) option. Internal voltage sen-
sors, located on the source side, indicate voltage magni-
tude within an accuracy 2% or better and a phase degree
accuracy within 1.5 degrees (includes sensor, cable, and
control). The 4-pin receptacle accessory is pre-wired to the
voltage inputs on the control. Refer to Service Instructions
S280-42-1 NOVA Three-Phase Recloser Installation and
Operation Instructions for additional setting information.
Incoming Power Receptacles
The Incoming Power Receptacle (Figures 32, 33, and 34)
allows the user to conveniently plug the power cable into
the control, eliminating the need for hardwiring to the
control. Various options are available based upon the input
power voltage, and phase sensing requirements. Table 8
includes the available input receptacles and cables for the
Form 6 pole-mount recloser control.
Cable Locking Sleeves
To prevent detachment of the control cable from the control
cabinet by unauthorized personnel, a cable-locking sleeve
(Catalog Number KME6-1772-1) is available to enclose the
cable plug. The plug is passed through the sleeve and the
sleeve is then fastened from inside the control cabinet.
There is no access to the cable receptacle without opening
the locked cabinet door and detaching the sleeve.
120 VAC GFI Duplex Outlet
The GFI Duplex Outlet (Catalog Number KME6-1776) is
available for controls powered by 120 VAC or 240 VAC
three-wire supply power. This convenience outlet is rated
for 15 Amperes and is accessible through the front door in
the control cabinet. The 120 VAC GFI Duplex Outlet is used
for many applications such as power for the MET Tester,
auxiliary measurement equipment, and supplemental
lighting.
Form 6 Microprocessor-Based Pole-mount Recloser Control Installation and Operation Instructions
32
ACCESSORIES
Description Catalog Number
120 VAC low-voltage closing 2-pin input and 2-pin output receptacles ................................... KME6-1775-A
120 VAC low-voltage closing with 3-pin input and 2-pin output receptacles ............................... KME6-1775-B
120 VAC low-voltage closing with inlet hole and 2-pin output receptacle .................................. KME6-1775-C
240 VAC low-voltage closing with 2-pin input and 2-pin output receptacle ................................ KME6-1775-D
240 VAC low-voltage closing with 3-pin input and 2-pin output receptacle ................................ KME6-1775-E
240 VAC low voltage closing, for 2-wire with inlet hole and 2-pin output receptacle ......................... KME6-1775-F
240 VAC low-voltage closing, for 3-wire with inlet hole and 2-pin output receptacle ......................... KME6-1775-G
120 VAC or 240 VAC input receptacle, 2-pin ....................................................... KME6-1775-H
120 VAC input receptacle, 3-pin ................................................................. KME6-1775-J
240 VAC input receptacle, 3-pin ................................................................. KME6-1775-K
AC Input Cable, 120 or 240 VAC, 2-wire for 2-pin input for use with KME6-1775-A, KME6-1775-D, or
KME6-1775-H receptacles. Replace X with desired length. Select from 10 to 80 feet. ........................ KMA11ME1-X
AC Input Cable, 240 VAC, 3-wire for 3-pin input for use with KME6-1775-E or KME6-1775-K receptacles.
Replace X with desired length. Select from 10 to 80 feet. .............................................. KME4-67-2-X
AC Input Cable, 120 VAC, 3-wire for 3-pin input for use with KME6-1775-B and KME6-1775-J receptacles.
Replace X with desired length. Select from 10 to 80 feet. .............................................. KME4-67-3-X
Low Voltage Closing Cable, 2-wire for use with KME6-1775-A, KME6-1775-B, KME6-1775-C, KME6-1775-D,
KME6-1775-E, and KME6-1775-F, and KME6-1775-G low voltage closing receptacles.
Replace X with desired length. Select from 10 to 80 feet. .............................................. KA13ME1-X
TABLE 8
Low Voltage Closing and Input Receptacles and Cables
TABLE 9
Internal Voltage Sensing
Catalog
Description Number
Internal Voltage Sensing input receptacle, 4-pin ................................ KME6-3799-1S
Note: Internal voltage sensing receptacle is
only compatible with reclosers equipped
with internal voltage sensors.
Note: The internal voltage sensing cable
(KA97ME) is ordered with the recloser. If a
replacement cable is required, contact your
Cooper Power Systems representative.
