Cooper Security 9751 - Figure 22. SELV and TNV Connectors

9751 Installation Guide 3. Installation
11976798 Page 31
1
2
3
4
5
6
7
1. Main connector (SELV) 5. Wire in comms connector (SELV)
2. Keypad connector (SELV) 6. Battery connector (SELV)
3. Telephone line connector (TNV) 7. 21VAC from transformer (SELV)
4. RJ11 connector (TNV)
Figure 22. SELV and TNV connectors
