25
SENSOR DETECTION
From this Sub-Menu the cameras can be selected to record when an Event Trigger is received from
the Sensor Inputs on the rear panel of the DVR. can be selected.
1) Highlight [SENSOR DETECTION] using (▲)(▼)buttons, and press [ENTER] button to enter.
The Sensor Detection Matrix will be displayed
2) Using the Cursor (▲)(▼)(◀)(▶)buttons, move the cursor to the segment that lines up with both the
camera channel to be recorded, and the Sensor Input to trigger the recording.
3) Press the [ENTER] button to toggle between
v(Recording ON) or o (Recording OFF)
4) Press the [MENU] button to exit the Matrix.
OPTIONS
From this Sub-Menu the duration of the recording (both Pre- & Post-Event) for an Event Trigger is set.
The Event Pop-Up option is also selectable from this Sub-Menu. If one Event is detected by the DVR,
the camera that is linked to that Event can Pop-Up to Full Screen on the Main Monitor Output
Screen. If more than one Event is triggered in the same period, the Main Monitor will go to the
Multi-Screen View. (4-way for XT04, 9-way for XT09 & 16-way for XT16)
1) Highlight [OPTIONS] using (▲)(▼)buttons, and press [ENTER] button to enter the Sub-Menu.
[SETUP-REC-EVENT REC(S/D)]
CHANNEL
1 2 3 4
S 01 V
S 02 V
S 03 V
S 04 V
ALL
3. SETUP
[SETUP-REC-EVENT-OPTIONS]
POST-RECORD TIME : <> 10 SEC>
PRE-RECORD TIME : > 4 SEC
POP-UP SCREEN : > YES
