Cornelius CCM0330 - Water Trough; CCM 48 Inch Wide Models; CCM 22 Inch Wide Models

Water System
Page D5
Water Trough
The water trough can be easily removed by the following procedures:
Mounting Screws
CCU0150/0220 Models
1. Disconnect power to the ice machine.
2. Shut the water supply off to the ice machine.
3. Remove water splash curtains when
applicable.
4. Remove water trough mounting screws.
5. Carefully remove water trough from the ice
machine.
6. Reverse procedure to reassemble.
CCM 22 Inch Wide Models
Mounting Screws
CCM 30 Inch Wide
CCM 48 Inch Wide Models
Mounting Screws
Mounting Screws
Mounting Screws
CCM1530 Model
Mounting Screws
CCU0300 Model
