Test Pressure Gauge:
A Output 1 operation indicator : Lights up when comparative output 1 is ON.
B Output 2 / analog voltage output operation indicator : Lights up when comparative output 2 is ON.
C Mode selection key : RUN MODE(This is the pressure detection state) / MENU SETTING MODE / PRO
MODE(not use it)
D Unit display
E LED display Display of pressure value・output mode・setting value
F Sub display
G Setting value UP key
H Setting value DOWN key
7.4.1 Output Mode
EASY mode · Hysteresis mode · Window comparator mode can be set. However, this tester uses Window
comparator mode.
Window comparator mode: Switch output can be turned ON or OFF within a programmed pressure range.
“Hi-1” or ”Lo-1” is displayed for comparative output 1 and “Hi-2” or ”Lo-2” for comparative output 2 on the
sub-display.
