Cosmo LS-1866 User Manual

70 11 INTERFACE
1
1
1
1
.
.
2
2
C
C
h
h
a
a
n
n
n
n
e
e
l
l
S
S
e
e
l
l
e
e
c
c
t
t
i
i
o
o
n
n
Channel changes are effected by entering a binary code to pins #21 to 24, pin #21 (CH#3) being the most
significant bit (MSB) and pin #24 being the least significant bit (LSB).
Channel
Channel#3
Channel#2
Channel#1
Channel#0
0
OFF
OFF
OFF
OFF
1
OFF
OFF
OFF
ON
2
OFF
OFF
ON
OFF
3
OFF
OFF
ON
ON
4
OFF
ON
OFF
OFF
5
OFF
ON
OFF
ON
6
OFF
ON
ON
OFF
7
OFF
ON
ON
ON
8
ON
OFF
OFF
OFF
9
ON
OFF
OFF
ON
A
ON
OFF
ON
OFF
B
ON
OFF
ON
ON
C
ON
ON
OFF
OFF
D
ON
ON
OFF
ON
E
ON
ON
ON
OFF
F
ON
ON
ON
ON
1
1
1
1
.
.
3
3
S
S
t
t
a
a
g
g
e
e
N
N
u
u
m
m
b
b
e
e
r
r
O
O
u
u
t
t
p
p
u
u
t
t
Leak test stages can be identified from combinations of stage # 0 and stage #1.
Stage
Stage #1
Stage #0
Stage number
Halted, DL1
OFF
OFF
“0”
CHG
OFF
ON
“1”
BAL
ON
OFF
“2”
DET
ON
ON
“3”
DL3 to end
*1
*1
*1
*1 In the DL3 to END stages, the stage number of each stage in which a judgement is rendered or a stop
signal is entered is held. In the event of a failure judgement in the BAL stage, for example, the stage
number of the END stage is set to “2”. This eases the process of discriminating of failing units.
Channel selection is enabled only in Remote. Refer to the timing charts.
NOTE
Channel 0 (CH0) is selected when Channel#3 to Channel#0 are not selected or
all are turned off.
NOTE
