3.3 DESIGN FEATURES
PTT Bracket Unit
3
4
5
 Figure: Bracket and power tilt-trim components
1 Upper mounting bolts
2 Lower mounting bolt
3 Tilt lock
4 Tilt ram
5 Trim rams
6 PTT anode (at underside)
7 Manual pressure relief valve
2
1
7
6
