3.3 DESIGN FEATURES
Trim Panel
 Figure: Trim control panel for a
triple outboard install
1 Port outboard trim-tilt switch
2 Center outboard trim-tilt switch
3 Starboard outboard trim-tilt switch
3
2
1
 Figure: Wireless Fob
1 Green LED
2 Start button
3 ON/OFF Button
4 Red LED
Wireless Fob
4
3
2
1
START
ON/OFF
