COX CXO300 - Helm Display Screens (7 and 12)

3.0 TECHNICAL SPECIFICATION
3.0 TECHNICAL SPECIFICATION
26
CXO300 OWNER’S MANUAL
3.3 DESIGN FEATURES
Helm display screens
7” screen
Helm display screens 12" screen
 Figure: Helm
display screen
(7”)
1 Main display
screen
2 Function
buttons (x8)
3 Menu button
4 Return button
 Figure: Helm display screen (12”)
1 Main display screen 2 Touch function button
1
2
3
4
2
1
