3.0 TECHNICAL SPECIFICATION
CXO300 OWNER’S MANUAL
 Figure: Display home screen
1 Port outboard ID
2 Port outboard gear position
3 Port outboard RPM
4 Port outboard trim position
5 Starboard outboard ID
6 Starboard outboard gear position
7 Starboard outboard RPM
8 Starboard outboard trim position
9 Vessel speed
10 Wind direction
11 Fuel tank levels
12 Vessel fuel consumption
Display home screen
1211
1
2
3 7
5
4
6
8
9
10
