OPERATOR’S MANUAL
33
OVERVIEW - DTT OPTA
DTT Opta introduces a world of choice, features and flexibility to the tool test environment, with
interchangable transducer modules, built-in printer option, and software features tailored to the
application requirement.
These options allow DTT Opta to be configured to closely match the user requirements, and a selection
of transducer modules can be made available to the operator to cover a broad torque range. Different
transducer modules are available with the transducer axis in either the vertical or horizontal plane.
In common with the Opta product family, DTT Opta’s range of software features can be individually
specified giving variations from a simple no-frills readout to a comprehensive audit tool with display of
torque curves and specialist measurement routines. As the software is common throughout the Opta
product family, users familiar with TorqueStar Opta will already know how to use DTT Opta, and vice-
versa.
PACKING LIST
The following items are supplied with the DTT Opta unit.
1 x DTT Opta 1 x Transducer 1 x User Manual (this book)
1 x Quick start guide 1 x Mains adaptor/charger 1 x Menu Navigation Guide
Please check these items are all present and notify Crane immediately of any shortages.
CARE & STORAGE
This unit is designed for indoor use only
Operating temperature range 5-40 degrees C
Storage temperature range 0-50 degrees C
The membrane keypad may be wiped clean with a soft damp cloth. The unit is not waterproofed and spillages should
be avoided.
THIS UNIT CONTAINS NO USER SERVICEABLE PARTS. ONLY QUALIFIED SERVICE PERSONNEL SHOULD
REPLACE OR FIT PARTS.
BATTERIES
The battery in the DTT Opta is a NiMH (Nickel Metal Hydride).
From fully discharged, the unit will require a 16 hour charge for normal use.
When the mains adaptor is plugged into the socket and switched on at the mains, the red LED will come on to
indicate the DTT Opta is charging correctly.
SECTION 2
