OPERATOR’S MANUAL
34
FEATURES AND DIMENSIONS
POWER Rechargeable batteries NiMH
Mains powered (needs optional charger)
WEIGHT Main Unit 3.5 Kg (without transducer and printer)
Transducer Module 1.3 Kg
Printer Module 0.22 Kg
DIMENSIONS Overall 255mm (L) x 255mm (W) x 79mm (H)
Transducer 105 mm (L) x 85 mm (W) x 79 mm (H)
Bottle top or adjustable component fixture:
10 - 130 mm (max gripping dimensions)
SPECIFICATIONS
MAINS ADAPTOR POWER REQUIREMENTS
Input: 230v AC 50HZ 700mA (UK and Euro models)
Input: 115v AC 60HZ 700mA (US models)
SECTION 2
