CONTROLS AND CONNECTIONS
Screen
SCREEN
KEYPAD
LEDs
INTEGRAL
PRINTER (optional)
INTERCHANGEABLE
TRANSDUCER MODULE
(VERTICAL)
JOINT KIT (OPTIONAL)
STATUS LED
CHARGER CONNECTED LED
CONNECTOR FOR MAINS
CHARGER
9 WAY CONNECTOR FOR
PC/PRINTER CABLE
CONNECTORS FOR
TRANSDUCER
MODULE
REAR OF UNIT
SCREEN
INTERCHANGEABLE
TRANSDUCER MODULE
(HORIZONTAL)
FIXING HOLES
FIXING HOLES
TRANSDUCER BOLT
FIXING HOLES
