OPERATOR’S MANUAL
37
SECTION 2
CONNECTING A TRANSDUCER MODULE
FITTING THE JOINT KIT
Ensure joint kit is located fully into Square Drive on the
Transducer Module.
FITTING THE BOTTLE TOP OR
ADJUSTABLE COMPONENT FIXTURE
Ensure bottle top fixture is located fully into Square Drive
on the Transducer Module.
