Do a Keypad
test.
Go to Test Menu, Platform
Movement. Check motor
Positions.. Send to home,
does Y Home say On?
Check Harness, Y
Motor, & I/O
Board.
See XY Not
Working
troubleshooting.
Send cup to “A”
shelf. Is cup in
correct location?
YES NO
Fire the plunger to ensure
correct location. Repeat
“A-E” cycle two to three
times. Is cup in correct
location?
YES NO
Repeat “A-E” cycle two to
three times. Does cup
position get worse?
YES NO
Enter Security Code Menu, enter
Manufacturing Security Code
5555, go to Factory Setup, Shelf
Offset setting and adjust offset as
needed.
CUP AT WRONG LOCATION
HIGH/LOW or Y AXIS
Close door
and test vend.
Is shelf setting correct?
YES NO
To Next Page
