Close door and do a test vend
with money. Does it work?
YES NO
Open service door. Pull top door
switch out and do a test vend with
money. Does it work?
YES NO
Go to Test Menu, Port &
Cup Sensors, manually
close the delivery port
door. Does Port Close say
On?
YES NO
Check, repair, and
replace door switch
components: mounting
bracket, strike plate,
switch, and harness.
Is port open
all the way?
YES NO
Enter Test Menu, Press 2 to
open port. Does the Port
Open Switch change to On
and the Port Close Switch
change to Off?
YES NO
Check, repair,
and replace
door close
switch.
DELIVERY PORT DOOR
WORKS IN FACTORY
DIAGNOSTICS BUT
NOT IN SALES MODE
Check for
physical
obstructions.
Check, repair, and
replace door open
switch, harness,
port motor.
To Next Page
