Creality Ender-3 User Manual

13. Power supply
14. Voltage regulator
15. Y-axis limit switch
16. Y-axis motor
17. Indication knob!
18. E-axis motor
19. X-axis motor
20. Coupling
21. Z-axis limit switch
22. Z-axis motor
23. Power switch and socket
Equipment parameters
Basic Parameters
Model: Ender-3 V2
Print size: 220*220*250mm
Forming technology: FDM
Number of nozzle: 1
Layer thickness: 0.lmm-0.4mm
Nozzle diameter: Standard
X-/ axis precision: ±0.lmm
Filament: ¢1.75mm PLA
File format: STL/OBJ/AMF
Working mode: Memory card offline printing or on line printing
Compatible slicing software: 3D Creator Slicer, Repetier-Host, Cura, Simplify3D
Power specification: Input: AC 115-230V 50/60Hz Output: DC 24V
Total power: 350W
Hotbed temperature: <l00’C
Nozzle temperature: <250’C
Resume printing function: Yes
Filament sensor: No
Dual z-axis screws: No
Language switch: English
Computer operating system: Windows XP/Vista/7 /10/MAC/Linux
Print speed: <180mm/s, 30-60mm/s normally
Spare parts
1. Printer base x 1
2. Display kit x 1

Creality Ender-3 Specifications

General

Build Volume	220 x 220 x 250 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Max Nozzle Temperature	255°C
Max Bed Temperature	110°C
Connectivity	SD card, USB
Supported Materials	PLA, ABS, TPU, PETG
Frame Material	Aluminum
Printing Technology	FDM (Fused Deposition Modeling)
Machine Dimensions	440 x 410 x 465 mm
Display	LCD
Bed Leveling	Manual
Print Speed	180 mm/s
Power Supply	24V
