Crestron DGE-100 Supplemental Guide

2 • DGE-100/DM-DGE-200-C: Digital Graphics Engines Supplemental Guide – DOC. 7696C
Product Features
Refer to the following chart to determine the product features that are available on the
DGE-100 and DM-DGE-200-C digital graphics engines.
DGE-100/DM-DGE-200-C Feature Chart
FEATURE CLASS FEATURE DGE-100 DM-DGE-200-C
General
Size Varies by display
Varies by display
Screen resolution Varies by display Varies by display
HDMI® input 1920 x 1080 max 1920 x 1080 max
DigitalMedia™ input N/A Up to 4K@30Hz 4:4:4
HDMI output 1920 x 1200@60Hz max
1920 x 1080@60Hz
3840 x 2160@30Hz
RS-232
Yes
Yes
IR
Yes
Yes
CEC
Yes
Yes
Audio out LPCM, up to 8 channel LPCM, up to 8 channel
HDCP
HDMI input HDCP 1.4 HDCP 1.4
DigitalMedia Input N/A HDCP 2.2
HDMI output HDCP 1.4 HDCP 2.2
Security
AES-128/TLS security
Yes/TLS 1.2
Yes/TLS 1.2
802.1x
Yes
Yes
Active Directory® software
authentication
Yes
Yes
Crestron AirBoard™
Whiteboard Capture
System
Supported as a video
source
Yes,
selectable as a source
within Smart Graphics®
video window object
Yes as of 1/2019 FW
release,
selectable as a
source within
Smart Graphics video
window object
Supported User
Interfaces
PinPoint UX No
No, depreciated as of
1/2019 FW release.
Use
AM-300 instead.
Custom Smart Graphics
project
Yes
Yes
Crestron Pyng® OS native
project
No No
Crestron Pyng OS Smart
Graphics project
Yes
Yes
Firmware Auto Update
Supported?
Yes as of 1/2019 FW
release
, disabled by
default
Yes as of 1/2019 FW
release
, disabled by
default
Crestron Virtual
Control (VC-4)
Supported?
Yes as of 1/2019 FW
release
Yes as of 1/2019 FW
release
RSTP
Default State
Enabled (Disabled will
become the default state
in a future release.)
Enabled (Disabled will
become the default state
in a future release.)
(Continued on following page)
