Crestron TSW-70 Series User Manual

66 • TSW-70 Series ProductManual—Doc.8550E
Power
PoE(Powerover
Ethernet)
IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power
management;
Requests 30 W (PoE+Class4) from an 802.3at Type 2 PSE without LLDP;
Requests 15.4 W (PoEClass0) from an 802.3af (or 802.3at Type 1)PSE
Environmental
Temperature 32 to 104 °F (0 to 40 °C)
Humidity 10% to 95% RH (noncondensing)
Heat Dissipation 44 BTU/hr
Construction
Housing Plastic, smooth black or white finish, edge-to-edge glass with black or white
surround
Mounting Surface mount over a 2 or 3-gang US electrical box, 2-gang European (DIN
49073) electrical box, or 2-gang UK (BS 4662) electrical box;
Lectern mount over a 2in. H x 3-3/4in. W (51mmHx 96mmW)cutout;
1-3/8in.(35mm) minimum mounting depth;
Wall mount, surface mount, and rack options available separately
Dimensions
Height 4.17 in. (106 mm)
Width 6.80 in. (173 mm)
Depth 1.99in. (51 mm)
Dimensions do not include mounting bracket or add-on accessories
Weight
14.11 oz (400 g)
Compliance
Regulatory Model: M201923002
IC, CE, FCC Part 15 Class B digital device
