CS-Lab CSMIO/IP-M User Manual

1.3 Standards compliance
CSMIO/IP-M controllers were designed and made in accordance with the national and international
standards for industrial control systems based on electronic components:
• Detailed requirements for programmable controllers: working characteristics, shock resistance,
safety etc. EN61131-2 (IEC1131-2), CSA 22.2, UL508
• Compliance with European Guidelines (low voltage, the level of electromagnetic interference
Electromagnetic Compability), the CE marking.
• Electrical and non-combustible properties of insulation materials: UL 746C, UL 94, etc.
• The Product made in lead-free technology, RoHS compliant.
1.4 Specification
Parameter
Value
Digital inputs
12
Digital outputs
4
Relay outputs
2
Analog inputs
2
Analog outputs
2
Supply voltage
24VDC +/-10%
Power consumption
5W
Maximum I/O Voltage
30VDC
Maximum output line load
250mA
Analog Input Voltage
0-10VDC
Analog Output - Maximum Load
5mA
Axis Drives control type
(STEP/DIR)
Maximum frequency of the STEP signal
125kHz
STEP Signal Duty Cycle
50%
PC communications
Ethernet 10/100Mb
Ambient temperature range
0
o
C to +60
o
C
Relative Humidity (Non-Condensing)
10% to 95%
(without condensation)
The STEP outputs signal frequency is in no way limited by the „Kernel speed” settings in Mach3 program.
While using the CSMIO/IP-M controller this Mach3’s configuration parameter is unused and can be set at
any value.
CS- Lab s.c. – CNC CSMIO/IP- M controller
Page 6
