CTX NEXT User Manual

Instrument characteristics:
HARDWARE CHARACTERISTICS
Display Touch 7’’ LCD 800 x 480 pixel
CPU Processor 32 bit 80Mhz - 512Kb Flash – 128Kb Ram – 1Mb EEprom
Archive memory Flash 512KB serial
Calendar
Clock Calendar with Backup Battery.
Clock frequency 32,768 Khz
Serial interface RS485
Dosage relay
Available in connection box
4 ON / OFF Free
(max 15A 230Vac resistive load, max 5A 230Vac inductive load, with
interference suppression varistors).
See table 1 for configuration
Alarm relay
Available in connection box
1 In Exchange (Cumulative for all the Alarms)
(max 6A 230Vac resistive load, max 1.5A 230Vac inductive load, with
interference suppression varistors)
Dosage Enabling 1 Active Digital Input +5Vdc – already wired
Power Supply
100-240Vac 50/60 Hz
Absorption Max 12VA
Protection rating
IP65 (controller)
Casing 594x754x197 mm (LxHxP)
Weight About 10 Kg
Operating pressure >0.5 atm with Δatm in/out >0.5atm
Maximum pressure
5 atm
48
ENGLISH

CTX NEXT Specifications

General

Brand	CTX
Model	NEXT
Category	Controller
Language	English
